| 브랜드 이름: | KOMAI |
| 모델 번호: | KM-AB006 |
| MOQ: | 2개 |
| 가격: | Negotiate |
| 지불 조건: | T/T, 서부 동맹 |
| 공급 능력: | 달 당 5000PCS |
Airport Full Height AB Swing Turnstile Gate Security Entrance With Gloden Color
Production Description :
The intelligent AB Full Height turnstile Gate has a lossless modular
mechanism structure, and has an advanced brushless servo control system and servo motor control technology independently developed by us. Th
turnstile adopts servo motor, so as to make the speed gate turnstile with advantages of high stability, high safety, long life service, accurate
detection, fast, stable and silent running, etc
The intelligent AB Full Height turnstile Gate has strong waterproof and dustproof capabilities, and is suitable for high-end indoor and outdoor
occasions such as office buildings, factories, airports, government agencies, schools, hospitals, casino,and leisure venues etc.
it is a swing barrier with a modular design that realizes fasts witching between different readers, and reader installation can be completed by merely pull-out and plug-in. After installing the corresponding readers, it can support multiple verification method, including RFID, fingerprint, QR code, passport , palm verification,visible light facial recognition can realize toothless entrance control that avoids hands exposing to bacteria and boost public hygienic security.
Features :
Brush less servo motor with 240 0 line position feedback
Current+position double detection, adjustable sensitivity
The switch speed is fast, and it is stable and does not shake.
Work with sensors, 10-20 pairs per lane
One way/ two way access control
Passable on power failure
Lane width: 600 mm/ 900 mm
Normal close/normal open
Door material: Acrylic , tempered glass( optional)
Door close time: 1-60s, 10s ( default)
One card one person ( default), Group pass for Continuous swiping card ( optional)
Door bounce back once hit block during movement
Compatible with various types of access control system
A door normal close(open by sensor), B door normal open(by swipe passport), B door is triggered to close when there is tailgating from A door.
Date sheet:
| Power Requirements | AC 100 ~ 120V / 200 ~ 240V, 50 / 60Hz |
| Working Temperature | -28°C ~ 60°C |
| Working Humidity | 20% ~ 95% (non-condensing) |
| Working Environment | Indoor / Outdoor (if sheltered) |
| Lane Width (mm) | 600mm-1000mm |
| Infrared Sensor | 10 pairs |
| Dimension(L*W*H) | 2000 * 220 * 1000 (mm) ( size can be customized) |
| Dimension with Packing(L*W*H) | 2060 * 280 * 1150(mm) |
| Weight with Packing(kg) | 120kg |
| LED Indicator | Support |
| Cabinet Material | 304#sus, 316SUS (optional) powder coated (optional) |
| Lid Material | 304#sus, |
| Barrier Material | Acrylic glass/tempered glass ( optional) |
| Barrier Movement | Indoor/ outdoor |
| Emergency Mode | Yes |
| MCBF | 10,000,000 times |
| Warranty | 1 year |
